7000-series assembly & installation
video guides
Due to the number of configurations and options, we have split the install instruction videos into multiple segments for assembly and then installation. We recommend assembling everything prior to beginning installation.
assembly instructions
assembly video
Fuel Tank + transfer case skids
How to assemble the transfer case skid, and front/rear fuel tank skids.
watch nowassembly video
transfer case + fuel tank skids
How to assemble the transfer case skid, and front/rear fuel tank skids.
watch nowengine skids
Videos for 392, 2.0 and 3.6 Engine Skid Assembly coming soon. Assembly is done with basic hand tools, and is fairly straight forward to attach UHMW, steel bracketry and aluminum.
Torque specs:
3/8" countersunk bolts 18 ft/bs
1/4" countersunk bolts 28 in/lbs
Scroll down for installation instructions!
install instructions
install video
fuel tank
Installation of the fuel tank, transfer case and crossmembers is done together. Click here to watch the fuel tank segment.
skip to 1:58install video
transfer case
Installation of the fuel tank, transfer case and crossmembers is done together. Click here to watch the transfer case segment.
skip to 13:56install video
rear exhaust skid
How to install the rear exhaust skid. Click here to watch this segment.
watch nowinstallation video
engine skid
Click here to watch the engine skid installation segment.
skip to 16:57
